PX1 - 1/2" / 13 mm AODD Original™ Series Metal Pump

Wilden PX1 - 13 mm (1/2") Metal Pump

Performance

WETTED HOUSINGS

(Water Chambers and Manifolds)

Material Ship Wt
Aluminum 6 kg (13 lbs)
316 S.S. 9 kg (20 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Aluminum
Air Valve Aluminum

FLOW RATE TO 62.8 LPM (16.6 GPM)

MAX PRESSURE = 8.6 BAR (125 PSI)

MAXIMUM SUCTION LIFT CAPABILITY

5.8 m (19') dry, 9.5 m Wet (31')

MAXIMUM DIAMETER SOLIDS

1.6 mm (1/16'')

DISPLACEMENT PER STROKE

  • Rubber- 0.09 l (.024 gal.)
  • TPE- 0.11 l (.029 gal.)
  • PTFE- 0.09 l (.024 gal)
ELASTOMER OPTIONS
Material Temperature Limits
Buna-N -12.2 to +82.2 °C (+10 to +180 °F)
EPDM -51.1 to +137.8 °C (-60 to +280 °F)
Neoprene -17.8 to +93.3 °C (+0 to +200 °F)
Polyurethane -12.2 to +65.6 °C (+10 to +150 °F)
PTFE +4.4 to +104.4 °C (+40 to +220 °F)
Saniflex™ -28.9 to +104.4 °C (+20 to +220 °F)
FKM -40 to +176.7 °C (-40 to +350 °F)
Wil-Flex™ -40 to +107.2 °C (-40 to +225 °F)
ENGINEERING OPERATION & MAINTENANCE MANUAL
P1_PX1_ORG_MTL_PERF_15.pdf
P1-PX1-Metal-EOM.pdf
DIMENSIONAL DRAWINGS (CAD REQUIRED)
PX1_Metal_Aluminum.ZIP
PX1-M.dxf
FLYERS
PROFLOX-ADV-MTL-FLYER-05.pdf
WIL_10301_F_06_usa.pdf
WIL_50004_F_03 PX SALES Competitive Matrix.pdf
GENERAL SPECIFICATIONS
CSA_Certificate_12-14-06.pdf
CSA-PX1 PPT.ppt
General-Brochure_WIL-18040-C-05.pdf
Get_X_Mechanical_Demo_Anim.wmv
Original-Brochure_WIL-10010-C-10.pdf
PR-1504 Natural Gas-PX1.pdf
PR-1516&1517-UL 79.pdf
Pro-Flo_X_pre-release.swf
PX 1 & PX200 UL PPT.ppt
