Wilden PX8 - 51 mm (2") Metal Pump

FLOW RATE TO 685 LPM (181 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)

WETTED HOUSINGS
(Water Chambers and Manifolds)

Material Ship Wt
Aluminum 35 kg (78 lbs)
Ductile Iron 49 kg (109 lbs)
Stainless Steel 53 kg (117 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Aluminum, Stainless Steel
Air Valve Aluminum, Stainless Steel

MAXIMUM SUCTION LIFT CAPABILITY
7.4 m (24.4')

MAXIMUM DIAMETER SOLIDS
6.4 mm (1/4")

ELASTOMER OPTIONS
Material Temperature Limits
Buna-N® -12.2 (+10) to +65.6 (+150) °C (F°)
Neoprene -17.8 (+0) to +93.3 (+200) °C (F°)
EPDM™ -51.1 (-60) to +137.8 (+280) °C (F°)
Polyurethane -12.2 (+10) to +65.6 (+150) °C (F°)
Saniflex™ -28.9 (+20) to +104.4 (+220) °C (F°)
PTFE +4.4 (+40) to +104.4 (+220) °C (F°)
Viton® -40 (-40) to +176.7 (+350) °C (F°)
Wil-Flex™ -40 (-40) to +107.2 (+225) °C (F°)
