Wilden PX4 - 38 mm (1 1/2") Metal Pump

FLOW RATE TO 347 LPM (92 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)

WETTED HOUSINGS
(Water Chambers and Manifolds)

Material Ship Wt
Aluminum 21 kg (46 lbs)
Ductile Iron 30 kg (66 lbs)
Stainless Steel 28 kg (67 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Aluminum, Stainless Steel
Air Valve Aluminum, Stainless Steel

MAXIMUM SUCTION LIFT CAPABILITY
6.9 m (22.7')

MAXIMUM DIAMETER SOLIDS
4.8 mm (3/16")

ELASTOMER OPTIONS
Material Temperature Limits
Buna-N® -12.2 (+10) to +65.6 (+150) °C (F°)
Neoprene -17.8 (+0) to +93.3 (+200) °C (F°)
EPDM™ -51.1 (-60) to +137.8 (+280) °C (F°)
Polyurethane -12.2 (+10) to +65.6 (+150) °C (F°)
Saniflex™ -28.9 (+20) to +104.4 (+220) °C (F°)
PTFE +4.4 (+40) to +104.4 (+220) °C (F°)
Viton® -40 (-40) to +176.7 (+350) °C (F°)
Wil-Flex™ -40 (-40) to +107.2 (+225) °C (F°)
