FLOW RATE TO 1021 LPM (270 GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)
WETTED HOUSINGS
(Water Chambers and Manifolds)
| Material | Ship Wt |
| Aluminum | 83 kg (182 lbs) |
| 316 S.S. | 125 kg (275 lbs) |
| Alloy C | 130 kg (287 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
| Center Section | Aluminum, Stainless Steel, Polypropylene |
| Air Valve | Aluminum, Stainless Steel, Polypropylene |
MAXIMUM SUCTION LIFT CAPABILITY
8.8 m (28.9') Wet
MAXIMUM DIAMETER SOLIDS
12.7 mm (1/2")
