Wilden PX15 - 76 mm (3") Metal Pump

FLOW RATE TO 918 LPM (243GPM)
MAX PRESSURE = 8.6 BAR (125 PSI)

WETTED HOUSINGS
(Water Chambers and Manifolds)

Material Ship Wt
Aluminum 60 kg (132 lbs)
316 S.S. 90 kg (198 lbs)
Cast Iron 98 kg (216 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Aluminum, Stainless Steel, Polypropylene
Air Valve Aluminum, Stainless Steel, Polypropylene

MAXIMUM SUCTION LIFT CAPABILITY
9.5 m (31.2') Wet

MAXIMUM DIAMETER SOLIDS
9.5 mm (3/8")

ELASTOMER OPTIONS
Material Temperature Limits
Buna-N® -12.2 (+10) to +65.6 (+150) °C (F°)
Neoprene -17.8 (+0) to +93.3 (+200) °C (F°)
EPDM™ -51.1 (-60) to +137.8 (+280) °C (F°)
Polyurethane -12.2 (+10) to +65.6 (+150) °C (F°)
Saniflex™ -28.9 (+20) to +104.4 (+220) °C (F°)
PTFE +4.4 (+40) to +104.4 (+220) °C (F°)
Viton® -40 (-40) to +176.7 (+350) °C (F°)
Wil-Flex™ -40 (-40) to +107.2 (+225) °C (F°)
