GPX220 - 1" / 25 mm Metal Natural Gas-Operated Double-Diaphragm Pump

GPX220 - 1" / 25 mm Metal Natural Gas-Operated Double-Diaphragm Pump

Performance

WETTED HOUSINGS

(Liquid Chambers and Manifolds)

Material Ship Wt
Aluminum 15 kg (34 lbs)
Stainless Steel 28 kg (61 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Aluminum
Air Valve Aluminum

FLOW RATE TO 206 LPM (55 GPM)

MAX PRESSURE = 6.9 BAR (100 PSI)

MAXIMUM SUCTION LIFT CAPABILITY


5.9 m (19.3') Dry, 9.0 m (29.5') Wet

MAXIMUM DIAMETER SOLIDS

6.4 mm (1/4'')

DISPLACEMENT PER STROKE

  • Rubber - 0.3 l (0.08 gal)
  • Reduced-Stroke PTFE - 0.23 l (0.06 gal)
ELASTOMER OPTIONS
Material Temperature Limits
Buna-N -12 to +82°C (+10 to +180°F)
PTFE +4 to +104°C (+40 to +220°F)
