Performance
WETTED HOUSINGS
(Liquid Chambers and Manifolds)
| Material | Ship Wt |
|---|---|
| Aluminum | 6 kg (13 lbs) |
| Stainless Steel | 9 kg (20 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
|---|---|
| Center Section | Aluminum |
| Air Valve | Aluminum |
FLOW RATE TO 61.7 LPM (16.3 GPM)
MAX PRESSURE = 6.9 BAR (100 PSI)
MAXIMUM SUCTION LIFT CAPABILITY
5.9 m (19.3') Dry, 7.9 m (26.1') Wet
MAXIMUM DIAMETER SOLIDS
1.6 mm (1/16")
DISPLACEMENT PER STROKE
- Rubber - 0.09 l (0.023 gal)
